- Place of Origin: Beijing
- Brand Name: Hongyu
- Model Number: YH830
1. Scope of application:
For adult patients with ARDS, hypoventilation syndrome, for bi-level non-invasive
ventilation in a hospital or home.
2.Specifications
1. | Working mode | CPAP, S, T, ST, VGPS. |
2. | Inspiratory pressure | 4-30 cmH2O (0.5 cmH2O interval) |
3. | Expiratory pressure | 4-30 cmH2O (0.5 cmH2O interval) |
4. | Treatment pressure | 4-20 cmH2O (in CPAP mode, 0.5 cmH2O interval) |
5. | Delayed boost | 0-45 minutes (interval of 5 minutes) |
6. | Breathing frequency | 5-50 times / minute (interval 1 time / minute) |
7. | Breathing ratio | 10-70% (interval of 1%) |
8. | Rise time | 1-5 steps (1 step interval, 1 step rises fastest, 5 steps rises ) |
9. | Inhalation sensitivity | 1-5 steps |
10. | Tidal volume | 50-1500ml (effective in VGPS mode, interval 50ml) |
3.VGPS(same with AVAPS,can set Target tidal volume)mode:
3.1 Maximum IPAP value adjustable range: 4-30 cmH2O
3.2 Adjustable range of minimum IPAP value: 4-30 cmH2O
3.3 EPAP value adjustable range: 4-30 cmH2O
3.4 Target Tidal Volume: 50-1500ml
4. Display range of monitoring setting parameters:
4.1 Respiratory waveform can be displayed;
4.2 Current mode: CPAP, S, T, ST, VGPS
4.3 Inspiratory pressure: 4-30 cmH2O
4.4 Expiratory pressure: 4-30 cmH2O
4.5 Breathing frequency: 5-50 times / minute
4.6 Breathing ratio: 10-70%
4.7 Air leakage: 20-99.9lpm
4.8 Tidal volume: 50-1500ml
4.9 minute ventilation: 0-50lpm
4.10 Blood oxygen saturation: 70-100%
4.11 Pulse rate: 25-250bpm
4.12 Delay boost: 0-45 minutes
